WD Parts: LP style pickup toggle switch

Switchcraft 3 Position Toggle Switch Exact Replacement For Gibson Les Paul #12010X

This is the exact Switchcraft® straight toggle switch with 3/16 in. threaded bushing length as used by Gibson® on the Les Paul® model guitars. Many manufacturers have adopted using this switch on similar two pickup instruments where the thread does not pass through a thicker top than the bushing length. The addition of deep toggle switch nut may be used to extend bushing length to securely fasten it to an instrument with a carved top. Switchcraft #12010X.This product comes pre-packaged from Switchcraft® with a cream color switch tip and nickel body finish.

Electrical:

• Contact Ratings: Fine silver contacts rated at 3A, 300W maximum AC non-inductive load standard.
• Leakage Resistance: 1,000 MW or greater
• Dielectric Strength: 250 VDC

Materials:

• Frame: Steel, plated
• Bushing and Shaft: Copper alloy, plated
• Springs: Copper alloy
• Knob: Molded thermoplastic
• Mounting Hardware: Knurled copper alloy locknut T10711, supplied
• Insulation: Rigid plastic spacers with plastic tubing through stack. Rigid plastic and/or thermoplastic lifters. Thermoplastic cam on actuator end
