WD Parts: Custom 3 Position Short Frame Toggle Pickup Switch

WD Parts: Custom 3 Position Short Frame Toggle Pickup Switch

Regular price $34.95 CAD
Regular price Sale price $34.95 CAD
Sale Sold out

This short frame Switchcraft® straight toggle switch is a blend between the long WDE7SW for Les Paul® guitars and the right angle WDE6SW used in SG's® and is used either where body thickness will not accommodate the longer switch or where a more compact switch design is desired. This special switch was designed by WD Music Products®' VP Larry Davis and built by Switchcraft® as a high quality alternative to existing short frame switches.This product comes pre-packaged from Switchcraft® with a cream color switch tip.

Electrical:
  • Contact Ratings: Fine silver contacts rated at 3A, 300W maximum AC non-inductive load standard.
  • Leakage Resistance: 1,000 MW or greater
  • Dielectric Strength: 250 VDC
Materials:
  • Frame: Steel, plated
  • Bushing and Shaft: Copper alloy, plated
  • Springs: Copper alloy
  • Knob: Molded thermoplastic
  • Mounting Hardware: Knurled copper alloy locknut T10711, supplied
  • Insulation: Rigid plastic spacers with plastic tubing through stack. Rigid plastic and/or thermoplastic lifters. Thermoplastic cam on actuator end
